LED control box, 84x71x40mm, control of LED strips, IO-Link, analog, digital, M12 plug connector

Features

• •Analog input current/voltage
• •5 digital inputs
• •IO-Link interface Several operational modes that allow individual parameterization via IO-Link
• •The VY000009 controller is designed for controlling and operating the EY000002, EY000003 and EY000004 LED lights. Various operational modes can be set and controlled via an IO link master, for example VY000005. For example, the "filling level" operational mode can be used to display filling levels, pressures or rotation speeds. They are controlled via the analog input of the controller with 4 ... 20 mA or 0 ... 10 V, the display via a suitable LED light. The five digital inputs of the controller are available in the operational modes "Countdown", "Segment display" or "Status display" for displaying process or system statuses. Time sequences can be displayed in the "Countdown" operational mode. The countdown can be started, stopped and reset via an input on the controller. In the "Segments" operational mode, up to five segments can be controlled via inputs after appropriate parameterization. This allows, for example, a classic signal light to be mapped. In the "Status display" operational mode, the light up can be controlled completely in one color via an input in order to signal different system statuses. In all operational modes, fixed or user-defined colors as well as warning and alarm thresholds can be freely selected. A flashing and strobe mode can also be set to increase visibility.
