Temperature Detection – Probe

Features

• •Thermocouple acc. to DIN EN 60584
• •Resistant to vibrations and shocks
• •Can be connected to TS720, IM34 or IMETI
• •Max. temperature connector: 120 °C
• •2-wire technology
• •Process connection: Compression fitting
• •Bendable probe (min. bending radius: 3 × outside diameter)

Functional principle

Thermocouples are used for the detection and monitoring of temperatures to optimize and control a process. Typical applications are in machine and plant construction as well as in the process industry. The core element of the temperature probe is a pair of metallic conductors that are made of different materials and connected at one end. Due to the thermoelectric effect, the thermocouple provides a temperaturedependent voltage.
